CombiDiagnost R90
Cross functional DRF system
CombiDiagnost R90
Cross functional DRF system
CombiDiagnost R90 is a remote controlled fluoroscopy system in combination with high-end digital radiography, designed to improve room utilisation in a cost effective manner. A fully digital workflow, UNIQUE image quality and excellent dose management make the versatile system suitable for a wide range of examinations from pediatric to bariatric imaging.
Features
2-in-1 system - High end radiography and fluoroscopy
Philips CombiDiagnost R90 premium cross-functional system is a true all around performer. Applications include chest, spine, upper and lower extremities, skull, as well as gastro-intestinal exams, arthrography, venography, lymphography, myelography and Digital Subtraction Angiography (DSA).
Flexible geometry - Versatility in use
The remote controlled tiltable table (-90° to +90°) is ideal for all standard fluoroscopy studies and for traditional X-rays including image stitching. A tilting tube column mechanism enables angled projections in any table position. The tabletop can hold a patient weighing up to 284 kg (626 lbs.) without restricting movement. The intuitive touchscreen controls geometry movements and fluoroscopy parameters.
Grid-Controlled Fluoroscopy (GCF) - Fully automatic dose adjustment
GCF is an exclusive Philips technology of pulsed fluoroscopy, providing superb image quality at low dose. Dose management is achieved by the use of a grid-switch mechanism in the X-ray tube. Moreover, X-ray parameters kV, mA and time are controlled within each single pulse (in-pulse control).
Specifications
- Generator
- Power
- 65 kW, 80kW optional
- Tube voltage exposure
- 40 - 150 kV
- Exposure techniques
- Manual: kV-mAs or kV-mA-s Automatic Exposure Control (AEC) - Intelligent Exporuse (IQX)
- Tube voltage flouroscopy
- 40 - 125 kV
- Fluoroscopy techniques
- Pulsed fluoroscopy (PF), in-pulse controlled Grid-controlled fluoroscopy (GCF), in-pulse controlled
- Applicational Range
- Fluoroscopy
- Upper and lower gastro intestinal tract, urinary studies, ERCP, fluoroscopy guided injections, etc.
- Radiography
- skull, ribs, spine, pelvis, upper extremities, long spine, examinations of the lung, abdomen etc.,
- Geometry
- Table tilt angle
- -90°/+90°
- Motorized compressor
- 3 kg - 15 kg (6.6 lbs - 33.1 lbs) compression force
- Tube column movement range
- 160 cm (63")
- Source to Image Distance (SID)
- 113 cm – 183 cm (44" to 72")
- Maximum patient weight
- 284 kg (626 lbs) without limitations
- Table height
- 65 cm - 133 cm ( 25’’ – 52.2’’)
- Tube: SRM 0608 ROT GS 505 (GCF)
- Anode heat storage capacity
- 800 kHU (593kJ)
- Focal spot
- 0.6 /0.8
- Maximum voltage
- 125 kV (110 kV in GCF)
- Tube: SRO 33100 ROT380 (PCF)
- Anode heat storage capacity
- 300 kHU (200kJ)
- Focal spot
- 0.6 /1.6
- Maximum voltage
- 150 kV
- Dynamic Flat Detector
- Detector Size
- 43 cm x 43 cm (17"x17")
- Image matrix size
- 2,874 pixel x 2,840 pixel
- Pixel size
- 148 µm
- Acquisition mode PCF
- Up to 6 fps
- Acquisition mode GCF
- Up to 30 fps
- Tube: SRO 33100 ROT380 (for CS)
- Anode heat storage capacity
- 300 kHU (200kJ)
- Focal spot
- 0.6 /1.2
- Maximum voltage
- 150 kV
- Eleva Tube Head
- Control buttons
- 6 color coded control buttons for directions & light; capacitive sensor for three-axis brake-release
- Data displayed includes
- Patient data, preview images, generator settings, live camera image (optional)
- Full color LCD touch display
- 30.7 cm (12.1")
- Wireless detector: SkyPlate Large
- Type
- Digital Csl (Cesium Iodide) flat detector
- Detector size
- 35 cm x 43 cm (14" x 17")
- Image matrix size
- 2330 x 2846 pixel
- Active area
- 34.48 cm x 42.12 cm (13.6" x 16.6")
- Wireless detector: SkyPlate Small
- Image matrix size
- 1500 x 1920 pixel
- Active area
- 22.2 cm x 28.4 cm (8.7" x 11.2")
- Type
- Digital Csl (Cesium Iodide) flat detector
- Detector size
- 24 cm x 30 cm (app. 10" x 12")
- Digital Vertical Stand
- Detector Size
- Fixed detector 43 cm x 43 cm 17" x 17") or alternatively SkyPlate Detector 35 cm x 43 cm (14" x 17")
- Motorized tilting
- Optional, -20° to +90°
- Vertical travel
- 30 cm - 180 cm (11.8" - 5'11")
