Tempus Pro Rugged, advanced monitor

Tempus Pro

Rugged, advanced monitor

989706000051

Find similar products

The Tempus Pro places the needs of the prehospital care professional at the heart of its design. Ground-breaking in functionality, it is light enough to carry and small enough to hold in one hand. Rugged, yet highly intuitive to operate, it can easily be deployed in a wide range of clinical scenarios, with advanced capabilities to allow clear, documented decision-making.

Features
Flexible and scalable to suit you

Unique, scalable platform

The functionality of the Tempus Pro system can be extended and upgraded when you need it to be. Add video laryngoscopy, ultrasound, defibrillation, advanced Masimo® parameters** and telemedicine to further advance capabilities. And access feature, software and system updates, and configuration tools to evolve your system in line with your requirements, budgets and protocols.
Extensive data capture ability

Capture, connect and decide

The Tempus Pro allows you to capture as much or as little data as you need. The on-screen smart patient care record can be augmented via the touchscreen, while you can choose how much data to collect and exactly what, when, where and how to share it. All data is encrypted and shared via authenticated, highly secure channels.
Easy to carry on your shoulder

Small, light, robust

The Tempus Pro is designed and built to meet the needs of prehospital care professionals. Weighing only 2.9 kg (6.4 lb) with a slender profile, the monitor allows you to flexibly carry all you need with you to the scene. The Tempus Pro is also highly durable – with an IP66 rating underlining its suitability for deployment in the most challenging environments.
Easy to deploy, even in hostile environments

Practical design and operation

The Tempus Pro features a 6.5" daylight-readable color display with high contrast mode, a glove-friendly touchscreen interface and multiple user-selectable display options. It is also night-vision compatible and features an integrated tactical switch for hostile environments.
  • Flexible and scalable to suit you
  • Extensive data capture ability
  • Easy to carry on your shoulder
  • Easy to deploy, even in hostile environments
See all features
Flexible and scalable to suit you

Unique, scalable platform

The functionality of the Tempus Pro system can be extended and upgraded when you need it to be. Add video laryngoscopy, ultrasound, defibrillation, advanced Masimo® parameters** and telemedicine to further advance capabilities. And access feature, software and system updates, and configuration tools to evolve your system in line with your requirements, budgets and protocols.
Extensive data capture ability

Capture, connect and decide

The Tempus Pro allows you to capture as much or as little data as you need. The on-screen smart patient care record can be augmented via the touchscreen, while you can choose how much data to collect and exactly what, when, where and how to share it. All data is encrypted and shared via authenticated, highly secure channels.
Easy to carry on your shoulder

Small, light, robust

The Tempus Pro is designed and built to meet the needs of prehospital care professionals. Weighing only 2.9 kg (6.4 lb) with a slender profile, the monitor allows you to flexibly carry all you need with you to the scene. The Tempus Pro is also highly durable – with an IP66 rating underlining its suitability for deployment in the most challenging environments.
Easy to deploy, even in hostile environments

Practical design and operation

The Tempus Pro features a 6.5" daylight-readable color display with high contrast mode, a glove-friendly touchscreen interface and multiple user-selectable display options. It is also night-vision compatible and features an integrated tactical switch for hostile environments.

Specifications

Physical dimensions
Physical dimensions
Standalone size
  • 263 x 216 x 100 mm (10.3" x 8.5" x 3.9")
Display
  • Color 165 mm (6.5”) 640x480 pixels, 130 klux daylight readable display
Standalone weight
  • 2.9 kg (6.4 Ib) with battery and RapidPak clip only (with printer 3.2 kg (7 Ib))
Pulse oximetry - Total hemoglobin (SpHb® g/dL)²
Pulse oximetry - Total hemoglobin (SpHb® g/dL)²
Accuracy (adult/ped/infant)
  • 8 - 17 g/dL ± 1 g/dL
Range
  • 0-25 g/dL
Integral digital camera
Integral digital camera
Resolution
  • 3.2 megapixels
Video streaming
  • H264 algorithm (bandwidth dependent)
Images
  • Included in patient record
Ultrasound and video laryngoscopy²
Ultrasound and video laryngoscopy²
Karl Storz C-Mac (optional)
  • Video laryngoscope imager and single use blades
Interson (optional)
  • General purpose, 3.5 MHz and line placement 7.5 MHz
Pulse oximetry - Total oxygen content (SpOC®)²
Pulse oximetry - Total oxygen content (SpOC®)²
Range
  • 0-35 ml of O2/dL
Impedance respiration
Impedance respiration
Accuracy
  • ±2 RPM or ±2% whichever is greater
Range
  • 3-150 RPM
Anesthetic gas monitoring²
Anesthetic gas monitoring²
Display of AA gas vitals
  • Optional Masimo ISA OR+ anesthestic gas module
Contact temperature
Contact temperature
Measurement range
  • 20–45°C (68–113°F)
Resolution
  • ±0.1°C / ±0.2 °F; accuracy: ±0.1 ºC
Compatability³
  • 2 channel YSI 400 series
Invasive pressure²
Invasive pressure²
2 channels
  • 5 μV/V/mmHg, Response: 0–20 Hz (-3 dB)
Range
  • -99-310 mmHg
Expansion
  • Up to 4 channels via USB module²
Filters
  • 50-60 Hz notch
Noninvasive blood pressure
Noninvasive blood pressure
Pediatric range
  • 20-230 mm/Hg
Neonate range
  • 20-130 mmHg
Accuracy
  • ±3 mmHg or ±2% (whichever is greater)
Adult range
  • 20-260 mmHg
Cuffs
  • Neonate disposable 1-5, infant, child, adult, large adult, thigh, cuff kit
ECG monitoring
ECG monitoring
Acquisition sample rate
  • 500 Hz
ST elevation
  • ST elevation
3,4,5 and 12-lead monitoring
  • via standard snap-on electrode
Accuracy
  • ±3%, DC offset, ±300 mV dc
Frequency response
  • 0.05-175 Hz , ±3dB
Heart rate range
  • 30-300 bpm
Arrhythmia monitoring/alarms
  • Arrhythmia monitoring/alarms
QT segment measurement
  • with alarms²
Acquisition and interpretation
  • 12-lead acquisition² and 12-lead interpretation
Common mode rejection
  • 95 dB minimum, additional filters include mains, muscle, and low and high pass
Microstream etCO₂*
Microstream etCO₂*
Range
  • 0-150 mm/Hg
Flow rate (measured by volume)
  • 50 (42.5 ≤ flow ≤ 65) ml/min
Accuracy
  • 0–38 mmHg: ±2 mmHg; 39–150 mmHg: ±5% of reading; +0.08% per 1 mmHg over 38 mmHg⁹
Capnometry²
Capnometry²
Respiration rate accuracy
  • 0–70 BPM ±1 BPM 71–121 BPM ±2 BPM 122–149 BPM ±3 BPM
Respiration rate range
  • 1-149 bpm
Pulse oximetry - SpO₂
Pulse oximetry - SpO₂
Perfusion index
  • 0,02-20 %
Accuracy (adult/ped)
  • No motion or low perfusion ±2 digits 70–100%, motion ±3 digits 70–100%
Response
  • <lt/>1 second delay
Accuracy (neonate)
  • Motion, no motion and low perfusion ±3 digits 70–100%
Range
  • 1-100 %
Pleth Variability Index (PVI)²
  • Pleth Variability Index (PVi)²
Sensor
  • Comfortable, waterproof, soft-tip
Technology
  • Masimo rainbow SET®
Pulse oximetry - Carboxyhaemoglobin (SpCO®)²
Pulse oximetry - Carboxyhaemoglobin (SpCO®)²
Range
  • 0-99.9 %
Accuracy (adult/ped/infant)
  • 1-40 %, ± 3%
Pulse oximetry - Methemoglobin (SpMet®)²
Pulse oximetry - Methemoglobin (SpMet®)²
Accuracy (all ages)
  • 1-15 %, ± 1%
Range
  • 0-99.9 %
Operating time
Operating time
11.5 hours
  • Display brightness at 30%, ECG, SpO₂, EtCo₂, temp x2 and NBP every 15 minutes
Up to 14 hours
  • With battery saving mode activated⁴
10.75 hours
  • Display brightness at 60%, ECG, SpO₂, EtCo₂, temp x2 and NBP every 15 minutes
Pulse rate
Pulse rate
Range
  • 25-239 BPM
Accuracy (all ages)
  • No motion ≤3 digits, motion ≤5 digits
Physical dimensions
Physical dimensions
Standalone size
  • 263 x 216 x 100 mm (10.3" x 8.5" x 3.9")
Display
  • Color 165 mm (6.5”) 640x480 pixels, 130 klux daylight readable display
Pulse oximetry - Total hemoglobin (SpHb® g/dL)²
Pulse oximetry - Total hemoglobin (SpHb® g/dL)²
Accuracy (adult/ped/infant)
  • 8 - 17 g/dL ± 1 g/dL
Range
  • 0-25 g/dL
See all specifications
Physical dimensions
Physical dimensions
Standalone size
  • 263 x 216 x 100 mm (10.3" x 8.5" x 3.9")
Display
  • Color 165 mm (6.5”) 640x480 pixels, 130 klux daylight readable display
Standalone weight
  • 2.9 kg (6.4 Ib) with battery and RapidPak clip only (with printer 3.2 kg (7 Ib))
Pulse oximetry - Total hemoglobin (SpHb® g/dL)²
Pulse oximetry - Total hemoglobin (SpHb® g/dL)²
Accuracy (adult/ped/infant)
  • 8 - 17 g/dL ± 1 g/dL
Range
  • 0-25 g/dL
Integral digital camera
Integral digital camera
Resolution
  • 3.2 megapixels
Video streaming
  • H264 algorithm (bandwidth dependent)
Images
  • Included in patient record
Ultrasound and video laryngoscopy²
Ultrasound and video laryngoscopy²
Karl Storz C-Mac (optional)
  • Video laryngoscope imager and single use blades
Interson (optional)
  • General purpose, 3.5 MHz and line placement 7.5 MHz
Pulse oximetry - Total oxygen content (SpOC®)²
Pulse oximetry - Total oxygen content (SpOC®)²
Range
  • 0-35 ml of O2/dL
Impedance respiration
Impedance respiration
Accuracy
  • ±2 RPM or ±2% whichever is greater
Range
  • 3-150 RPM
Anesthetic gas monitoring²
Anesthetic gas monitoring²
Display of AA gas vitals
  • Optional Masimo ISA OR+ anesthestic gas module
Contact temperature
Contact temperature
Measurement range
  • 20–45°C (68–113°F)
Resolution
  • ±0.1°C / ±0.2 °F; accuracy: ±0.1 ºC
Compatability³
  • 2 channel YSI 400 series
Invasive pressure²
Invasive pressure²
2 channels
  • 5 μV/V/mmHg, Response: 0–20 Hz (-3 dB)
Range
  • -99-310 mmHg
Expansion
  • Up to 4 channels via USB module²
Filters
  • 50-60 Hz notch
Noninvasive blood pressure
Noninvasive blood pressure
Pediatric range
  • 20-230 mm/Hg
Neonate range
  • 20-130 mmHg
Accuracy
  • ±3 mmHg or ±2% (whichever is greater)
Adult range
  • 20-260 mmHg
Cuffs
  • Neonate disposable 1-5, infant, child, adult, large adult, thigh, cuff kit
ECG monitoring
ECG monitoring
Acquisition sample rate
  • 500 Hz
ST elevation
  • ST elevation
3,4,5 and 12-lead monitoring
  • via standard snap-on electrode
Accuracy
  • ±3%, DC offset, ±300 mV dc
Frequency response
  • 0.05-175 Hz , ±3dB
Heart rate range
  • 30-300 bpm
Arrhythmia monitoring/alarms
  • Arrhythmia monitoring/alarms
QT segment measurement
  • with alarms²
Acquisition and interpretation
  • 12-lead acquisition² and 12-lead interpretation
Common mode rejection
  • 95 dB minimum, additional filters include mains, muscle, and low and high pass
Microstream etCO₂*
Microstream etCO₂*
Range
  • 0-150 mm/Hg
Flow rate (measured by volume)
  • 50 (42.5 ≤ flow ≤ 65) ml/min
Accuracy
  • 0–38 mmHg: ±2 mmHg; 39–150 mmHg: ±5% of reading; +0.08% per 1 mmHg over 38 mmHg⁹
Capnometry²
Capnometry²
Respiration rate accuracy
  • 0–70 BPM ±1 BPM 71–121 BPM ±2 BPM 122–149 BPM ±3 BPM
Respiration rate range
  • 1-149 bpm
Pulse oximetry - SpO₂
Pulse oximetry - SpO₂
Perfusion index
  • 0,02-20 %
Accuracy (adult/ped)
  • No motion or low perfusion ±2 digits 70–100%, motion ±3 digits 70–100%
Response
  • <lt/>1 second delay
Accuracy (neonate)
  • Motion, no motion and low perfusion ±3 digits 70–100%
Range
  • 1-100 %
Pleth Variability Index (PVI)²
  • Pleth Variability Index (PVi)²
Sensor
  • Comfortable, waterproof, soft-tip
Technology
  • Masimo rainbow SET®
Pulse oximetry - Carboxyhaemoglobin (SpCO®)²
Pulse oximetry - Carboxyhaemoglobin (SpCO®)²
Range
  • 0-99.9 %
Accuracy (adult/ped/infant)
  • 1-40 %, ± 3%
Pulse oximetry - Methemoglobin (SpMet®)²
Pulse oximetry - Methemoglobin (SpMet®)²
Accuracy (all ages)
  • 1-15 %, ± 1%
Range
  • 0-99.9 %
Operating time
Operating time
11.5 hours
  • Display brightness at 30%, ECG, SpO₂, EtCo₂, temp x2 and NBP every 15 minutes
Up to 14 hours
  • With battery saving mode activated⁴
10.75 hours
  • Display brightness at 60%, ECG, SpO₂, EtCo₂, temp x2 and NBP every 15 minutes
Pulse rate
Pulse rate
Range
  • 25-239 BPM
Accuracy (all ages)
  • No motion ≤3 digits, motion ≤5 digits
  • ¹ Tempus Pro standalone weight: 6.4 lb (2.9 kg) nominal including battery, excluding IP module, accessories and printer.
  • ² Optional, additional feature.
  • ³ One channel fitted as standard, second channel is optional.
  • ⁴ Display active 50% of the time.
  • ** Optional advanced Masimo parameters include pleth variability index (PVi®), noninvasive hemoglobin (SpHb®) with total oxygen content (SpOC™), SpCO® and SpMet® Masimo®, Masimo rainbow SET®, PVi®, SpHb®, SpMet®, SpCO® and SpOC® are the property of Masimo Inc.
  • Oridion and Microstream are trademarks of Medtronic.
  • C-MAC is the property of Karl Storz.
  • * Uses Oridion Microstream technology
