Ingenia Elition 3.0T X
A revolutionary breakthrough in diagnostic quality – and speed
Ingenia Elition 3.0T X
A revolutionary breakthrough in diagnostic quality – and speed
The Philips Ingenia Elition solution offers cutting-edge MR imaging techniques, while setting new standards for clinical research in 3.0T imaging based on gradient- and RF designs. The Ingenia Elition delivers on superb image quality, and performs MRI exams up to 50% faster¹. Fast overall exam-time is achieved by improving patient handling setup time at the bore with the touchless guided patient setup, combined with accelerations in both 2D- and 3D scanning. Furthermore, the Ingenia Elition offers an immersive audio-visual experience to calm patients and guide them through MR exams.
Clinical image gallery
- SWIp
- 3D APT
- Coronal T2w TSE
- Axial DWI b15000
- 3D T1w TFE
- 3D VIEW PDw SPAIR
- DTI 128 directions
- Coronal T1w mDIXON XD TSE
- 3D VIEW FLAIR
- Axial T2w TSE
- DWI b600
- Axial T2w TSE
Features
Diagnostic confidence in neuro oncology
3D APT (Amide Proton Transfer) is a unique, contrast-free, brain MR imaging method. The presence of endogenous cellular proteins is used to produce an MR signal that directly correlates with cell proliferation, an indicator of tumoral activity. 3D APT can enhance your diagnostic confidence.
Up to 30% faster DWI images²
With Ingenia Elition’s high-performance gradients diffusion scans are up 30% faster while appearing sharper². An average of 70% higher contrast resolution can be achieved in diffusion imaging². SNR is further improved due to a TE up to 15% shorter in diffusion imaging.²
Up to 60% higher resolution³
Fully redesigned gradients combined with Compressed SENSE acceleration technology allow up to 60% higher spatial resolution³ in the same scan time, revealing more details for greater precision. This allows you, for example, to speed up your isotropic 3D MSK imaging. It’s precision made efficient.
Specifications
- Magnet system
- Field strength
- 3.0T
- Bore design
- 70 cm
- Magnet weight
- 4800 kg
- Typical homogeneity V-RMS
- ≤ 0.9 ppm (at 45 cm DSV)
- HeliumSave technology
- Yes (Zero boil-off)
- Maximum FOV
- 55 cm
- Cryogen boil-off rate
- 0 liter/hour (under regular scanning conditions)
- RF transmit
- Parallel RF transmission
- Yes
- Output power
- ≥ 2 × 18 kW
- RF Receive
- Number of independent receive channels
- Channel independent
- Location of analog-to-digital converter (ADC)
- Inside the coil, close to receive elements
- Signal chain from coil to reconstructor
- Fully digital
- dStream
- Yes
- Siting information
- Minimum siting requirement
- 3.4 m x 5.3 m
- Ceiling height (minimum)
- 2.56 m
- Single operator workflow
- SmartSelect
- Yes
- SmartExam
- Yes
- SmartTouch
- Yes
- SmartLink
- Yes
- AutoStart
- Yes
- SmartLine
- Yes
