Range of Transducers | Philips Lumify

Philips Lumify
Transducers

Produkt ultrasonograficzny S4-1 firmy Philips

S4-1 broadband sector array

4 to 1 MHz extended operating frequency range
2D, color Doppler, M-mode, advanced XRES and multivariate harmonic imaging
High resolution imaging for abdominal and cardiac applications: Echo, OB/GYN, Lung, Abdomen and FAST imaging preset optimizations
Center line marker
MicroB USB transducer with replaceable cable

Lumify C5-2 broadband curved array transducer

5 to 2 MHz extended operating frequency range
50mm radius of curvature
2D, color Doppler, M-mode, advanced XRES and multivariate harmonic imaging, SonoCT
High resolution imaging for deeper applications: abdominal, gall bladder, OB/GYN and lung imaging preset optimizations
Center line marker
MicroB USB transducer with replaceable cable

Produkt ultrasonograficzny s5-2 firmy Philips

Produkt ultrasonograficzny c5-2 firmy Philips

Produkt ultrasonograficzny L12-4 firmy Philips

Lumify L12-4 broadband linear array transducer

12 to 4 MHz extended operating frequency range
Aperture size: 34mm
2D, steerable color Doppler, M-mode, advanced XRES and multivariate harmonic imaging, SonoCT
High resolution imaging for shallow applications: Soft Tissue, Vascular, Superficial, Musculoskeletal, and Lung
Center line marker
MicroB USB transducer with replaceable cable

Excellent image quality in a mobile device

Thanks to the high-quality ultrasound images generated, Lumify allows for a quick and accurate assessment of patients in any situation. Advanced algorithms automatically optimise contrast and sharpness, and the intuitive touch interface makes it easy to accurately modify depth, gain, and Doppler speeds.

Clinical images

Gallery

Toggle view
By clicking on the link, you will be leaving the official Royal Philips ("Philips") website. Any links to third-party websites that may appear on this site are provided only for your convenience and in no way represent any affiliation or endorsement of the information provided on those linked websites. Philips makes no representations or warranties of any kind with regard to any third-party websites or the information contained therein.
I understand

You are about to visit a Philips global content page
Continue

Choose a transducer which fits your needs

The three Lumify transducers enable you to conduct a variety of scans depending on your patient’s needs. Each option offers a range of presets giving you a versatile portable ultrasound solution.

	S4-1 Sector transducer	L12-4 Linear transducer	C5-2 Convex transducer
Application	ECHO, FAST, Abdomen, Lung, OB/GYN	Lung, MSK, Soft Tissue, Superficial, Vascular	Abdomen, ECHO, FAST, Lung, OB/GYN
Bandwidth	4-1 MHz	12-4 MHz	5-2 MHz
Field of view	90°	34,5mm	67,3°
Footprint	20,2mm	34mm	50mm (radius of curvature)
Scan depth	Up to 24cm	Up to 12cm	Up to 30cm
Imaging features	2D, colour Doppler, M-mode, advanced XRES and multivariate harmonic imaging	2D, steerable colour Doppler, M-mode, advanced XRES and multivariate harmonic imaging, SonoCT	2D, colour Doppler, M-mode, advanced XRES and multivariate harmonic imaging, SonoCT

The power of Philips ultrasound
– in a mobile device.

Lumify works with your compatible smart device, giving you an incredible ultrasound system on top of the full functionality of the device. Just download the app via the Google Play Store, connect the USB ultrasound transducer, and start scanning.

Apple does not support Lumify at this time, but we are always exploring opportunities to expand support for all platforms.

Compatible devices

Click here to reference a range of compatible tablets and their specifications.

View devices (PDF) (82.0KB)

Mounting solutions

To learn more about possible mounting solutions for Lumify visit the GCX website.

Lumify is always at your side

The Lumify custom carry case is designed to be lightweight, comfortable and cleanable so that the Lumify USB ultrasound machine easily goes where you do.

Designed to fit:
